Dual Large Transformer Terminal (XY264-2P) 6 mm²

Description

Dual Large Transformer Terminal (XY264-2P) 6 mm²

General Features

  • Poles: 2P

  • Screw Pitch: 15mm (.591”)

  • Voltage Rating: 300V (UL) / 750V (IEC)

  • Current Rating: 20A  (UL) / 32A (IEC)

  • Cable Cross-Section Range: 0.5 – 6 mm² (20-10AWG)

Dimensions

FeatureValue
Number of Poles2P
Screw Pitch15mm (.591”)

Electrical Properties

StandardULIEC
Voltage Rating300V750V
Current Rating20A32A
Cable Cross-Section Range20-10AWG0.5 – 6mm²
Voltage ResistanceAC3000V/Min

Mechanical Properties

  • Torque: 1.2N.m (10.5Lb-ln)

  • Ambient Temperature: -40°C ~ +105°C

  • Strip Length: 10-12mm

Materials

PartMaterial
HousingPA66 (UL 94V-0)
Connection PointBrass, Tin Plated
Wire CageBrass, Nickel Plated
ScrewM4, Steel, Cr3+ Zn Plated
